Rs. 225.00Rs. 170.00
10 RPM 12V DC Geared Motor – extremely high torque, ultra-low speed motor designed for robotic lifts, automation gates, and precision gear-based systems.
The 10 RPM 12V DC Geared Motor is a slow-speed, ultra high torque motor ideal for high-load, precision-driven applications. With a rugged metal gearbox and a no-load speed of around 10 RPM at 12V, it’s perfect for use in robotic joints, automated barrier systems, motorized locks, pan-tilt units, and heavy-duty lifting platforms.
This motor features a 6mm D-shaped shaft for secure mounting and offers easy integration using pre-threaded holes on the gearbox face. Designed to operate reliably under continuous or stall loads, this motor is preferred in engineering prototypes, mechanical arms, and industrial actuators.
Its smooth torque delivery makes it perfect for projects requiring strong, consistent, and controlled motion at minimal speeds.
| Parameter | Specification |
|---|---|
| Motor Type | Brushed DC Geared Motor |
| Operating Voltage | 6V – 12V DC |
| Rated Voltage | 12V DC |
| Speed (No Load) | ~10 RPM @ 12V DC |
| Stall Torque | ~15–18 kg·cm (approximate) |
| Current Draw | ~500–700 mA (no-load), up to 2.5 A (under load) |
| Shaft Diameter | 6 mm (D-type) |
| Gearbox Material | All Metal Gears |
| Mounting Holes | Threaded holes on front gearbox plate |
| Weight | ~350–400 g |
| Applications | Robotic lifts, camera sliders, smart lockers, automation arms, heavy mechanical systems |
? Included in Package:
-
1 × 10 RPM 12V DC Geared Motor
