Rs. 300.00Rs. 275.00
3.5 RPM 12V DC Geared Motor – ultra-high torque, precision slow-speed motor for heavy-duty robotic arms, automation gates, and smart electromechanical systems.
The 3.5 RPM 12V DC Geared Motor is an ultra-slow speed, maximum torque motor designed for applications that require fine control, load holding, and slow rotation with stability. With a rugged metal gearbox, it provides exceptional torque output at just 3.5 rotations per minute.
Ideal for use in pan-tilt systems, camera sliders, automated display units, rotating platforms, robotic grippers, and servo-like actuators, this motor can handle demanding tasks with ease.
The 6mm D-shaped output shaft is compatible with a variety of mechanical parts, and the motor’s metal housing and pre-threaded mounting holes allow for solid integration into most automation projects.
Whether you're building an engineering prototype or a smart electromechanical solution, this motor ensures reliable performance in tight, torque-heavy conditions.
| Parameter | Specification |
|---|---|
| Motor Type | Brushed DC Geared Motor |
| Operating Voltage | 6V – 12V DC |
| Rated Voltage | 12V DC |
| Speed (No Load) | ~3.5 RPM @ 12V DC |
| Stall Torque | ~20–25 kg·cm (approximate) |
| Current Draw | ~600 mA (no-load), up to 2.5 A (under load) |
| Shaft Diameter | 6 mm (D-shape) |
| Gearbox Material | Full Metal |
| Mounting Holes | Threaded holes on the gearbox face |
| Weight | ~400–450 g |
| Applications | Robotic arms, motorized camera heads, smart doors, museum displays, slow rotating devices, Arduino automation |
? Included in Package:
-
1 × 3.5 RPM 12V DC Geared Motor
