Rs. 210.00Rs. 170.00
500 RPM 12V DC Geared Motor – reliable and efficient motor with medium torque output for wheels, drive systems, automation, and mechanical kits.
The 500 RPM 12V DC Geared Motor is a high-efficiency medium-speed motor designed for a wide range of robotics, automation, and DIY mechanical systems. Delivering a balance of speed and torque, it’s perfect for robotic wheels, mobile platforms, conveyor belts, and DIY automation where precision and control are needed.
The built-in metal gearbox provides smooth operation, extended life, and durability under various loads. This motor features a standard 6mm D-type shaft, making it compatible with most wheels and couplers.
Ideal for students, hobbyists, and engineers building 2WD/4WD robots, mechanical models, or motion-based prototypes.
| Parameter | Specification |
|---|---|
| Motor Type | Brushed DC Geared Motor |
| Operating Voltage | 6V – 12V DC |
| Rated Voltage | 12V DC |
| Speed (No-Load) | ~500 RPM @ 12V DC |
| Stall Torque | ~2.5–3.5 kg·cm (varies by make/model) |
| Current Draw | ~300 mA (no-load), up to 1.5 A (load) |
| Shaft Diameter | 6 mm D-type |
| Gearbox Material | Metal |
| Motor Body Material | Metal alloy |
| Weight | ~200–250 g |
| Mounting Holes | Threaded holes on gearbox faceplate |
| Applications | Robotics drive, RC vehicles, DIY systems, automation, small conveyors |
? Included in Package:
-
1 × 500 RPM 12V DC Geared Motor
